AltiumDesigner17原理图与PCB设计教程

 作　　者 ： 赵悦编

 出  版  社 ： 重庆大学出版社

 定　　价 ： 52.00

 ISBN 号 ： 9787568915618

 出版日期 ： 2019年7月

 版　　次 ： 1

 印　　次 ： 1

 页　　数 ： 306

 字　　数 ： 489000

 装　　帧 ： 平装

 开　　本 ： 16开

AltiumDesigner17原理图与PCB设计教程》以新版AltiumDesigner17为基础，全面讲述AltiumDesigner17电路设计的各种基本操作方法与技巧。全书共分**，主要内容包括：AltiumDesigner17概述，电路原理图参数设置，原理图设计，原理图的后续处理，层次化原理图设计，PCB设计，绘制PCB，创建集成元件库。该书主要特点是内容精练，起点高，知识新，系统性和实用性强。

《AltiumDesigner17原理图与PCB设计教程》可作为大中专院校电类专业和各种培训机构的教学用书，也可作为电子设计爱好者的自学辅导用书。

  • **章概述
  • 1．1AltiumDesigner的发展
  • 1．2AltiumDesigner功能
  • 1．3AltiumDesigner17软件的安装
  • 1．4AltiumDesigner17设计流程
  • 第2章电路原理图参数设置
  • 2．1原理图的组成
  • 2．2原理图的编辑环境
  • 2．3图纸的设置
  • 2．4原理图工作环境设置
  • 第3章原理图设计
  • 3．**件库的操作
  • 3．**器件操作
  • 3．3绘制电路原理图
  • 3．4实例
  • 第4章原理图的后续处理
  • 4．1原理图的全局编辑
  • 4．2编译与查错
  • 4．3生成各种报表
  • 4．4打印输出
  • 第5章层次化原理图的设计
  • 5．1层次电路原理图的基本概念
  • 5．2层次原理图的基本结构和组成
  • 5．3层次原理图的设计方法
  • 5．4层次原理图的切换
  • 第6章PCB图设计
  • 6．1PCB编辑器环境
  • 6．2PCB编辑器环境参数设置
  • 6．3PCB设计规则
  • *．*PcB编辑器的编辑功能
  • 6．5PCB图的绘制
  • 第7章绘制PCB
  • 7．1网络表的导入
  • 7．**件的布局
  • 7．3系统自动布线
  • 7．4调整布线
  • 7．5DRC检查
  • 7．6补泪滴和敷铜
  • 7．7报表输出和打印输出
  • 7．8综合实例
  • 第**创建集成元件库
  • 8．**件库介绍
  • 8．2AltiumDesigner17的元件库原理图编辑环境
  • 8．3创建C8051F320原理图模型
  • 8．4创建PCB元件库及元件封装
  • 8．5创建集成元件库
  • 8．**件封装库报表
  • 8．7综合实例
