Yangshengfu Peking Bluebird-Spannungssignalsensor JBF6187 Drei-Phasen-Vier-Draht-Vier-Draht-Dual-Wege-Geräteanpassungsanpassung

Yangshengfu Peking Bluebird-Spannungssignalsensor JBF6187 Drei-Phasen-Vier-Draht-Vier-Draht-Dual-Wege-Geräteanpassungsanpassung
Yangshengfu Peking Bluebird-Spannungssignalsensor JBF6187 Drei-Phasen-Vier-Draht-Vier-Draht-Dual-Wege-Geräteanpassungsanpassung
US$92,24
  • Stock: 100
  • Model: 10155091872329
  • Weight: 0.60kg
  • Dimensions: 20.00cm x 12.00cm x 6.00cm
+ Warenkorb
Buy Now
+ Wunschliste

How to Order & Pay

Shipping: Free Shipping & Customs Tax included are subject to change, please refer to the quote you received.

Delivery: Accurate and precise order tracking. Learn more

Package Safety: Refund for your damaged or lost package. Learn more

Payments:

Shop with confidence

Inspect item by item, verify, conduct quality checks, and upload authentic photos of the products.

Consolidate and repackage all items to reduce international logistics costs and facilitate international transportation.

Our customer service is always here if you need help. Click here to chat with us or Chat on WhatsApp

Please log in to view detailed product descriptions and select product options.
北大青鸟JBF6187双路电压信号传感器
一，简介
JBF6187型电压信号传感器属于双路三相四线交流电压型，应与本公司的 JBF-61S60 型消防设备电源状态监控器配接使用。其用于监控消防电源的工作状态，当消防电源发生供电中断，过压，欠压，缺相，错相等故障时，发出故障信息，以保证消防电源的正常工作状态，从而确保消防的可靠性。JBF6187 型电压信号传感器设计、制造和检定符合国家标准：GB 28184-2011《消防设备电源监控》的要求。
二 主要特性
1）传感器和监控器之间采用无极性两总线制连接方式，通讯稳定可靠，布线简便；
2）传感器设有两个指示灯，绿灯闪烁表示为正常工作状态，黄灯常亮表示为故障状态，能清楚地指示传感器的状态；
3）传感器具有同时对两路的三相四线制消防电源的电压值的实时监控功能；可在 100 秒内报出消防电源的供电中断，过压，欠压，缺相，错相等故障；
4）传感器能将实时的电压值、故障信号传送到配接的消防设备电源状态监控器。
三，主要参数
型 号：JBF6187
规 格：双路
检测对象：三相四线电源的电压值
额定工作电压：DC 24V
额定工作电流：5mA
电压测量范围：AC 220V
电压分辨率：1V
过压百分比：0%～20%
欠压百分比：0%～20%
通讯方式：无极性两总线
传输距离：1000m
温度：0℃～+40℃；
相对湿度：10%～93％（非凝露）
外形尺寸：132mm×89.5mm×58mm（L×W×H）
安装方式：35mm 标准导轨
四，安装与布线
1，安装方法
JBF61867 传感器安装方法：
1.将传感器安装在消防电源配电箱内，35mm 标准导轨安装；
2.将传感器固定。
注意：
1.务必在断电的情况下安装；
2.设备应安装在干燥的环境中；
3.安装时应确保设备安装牢固；
4.定期检查设备是否正常运行。
2，布线要求
对于电压线线径要求小不小于 1.5 ㎜。

本产品为定制产品，下单前请联系商家确认库存，未得到准确回复前，请勿下单，否则商家有权，谢谢合作

本产品为定制产品，货期3个月，如需下单请联系客服，介意慎拍。
